Imec and Cascade Microtech Develop First Automatic Probe System for Advanced 3D Chips

Unique Award-Winning Test System Enables Pre-Bond Probing of 3D Chips with Large-Array Fine-Pitch Micro-Bumps

Leuven (Belgium) – May 24, 2017 – Imec, the world-leading research and innovation hub in nano-electronics and digital technologies, and Cascade Microtech, a FormFactor company and worldwide leader in advanced wafer-probe solutions, today announced the successful development of a fully-automatic system for pre-bond testing of advanced 3D chips. Pre-bond testing is important to increase the yield of 3D stacked chips. The new system enables probing and hence testing of chips with large arrays of 40µm-pitch micro-bumps, on 300mm wafers. The relevance of this new tool is underlined by winning the 2017 National Instruments Engineering Impact Award yesterday at a ceremony in Austin, Texas.

As an emerging technology, 3D IC stacking still has many open options and technical challenges. One of these challenges is probing of the individual chips, before being stacked, to ensure a good yield of the 3D stacked ICs. The inter-chip connections of 3D stacked ICs are made by large arrays of fine-pitch micro-bumps which makes probing these bumps a challenge. Until today, the probing solution is to add dedicated pre-bond probe pads to the to-be-stacked dies, but this requires extra space and design effort and increases test time.

Imec and Cascade Microtech have now developed a fully automatic test cell that can provide test access by probing large arrays of fine-pitch micro-bumps. The system is based on a Cascade Microtech CM300 probe station and National Instruments PXI test instrumentation, complemented by in-house developed software for automatic test generation, data analysis, and visualization. The system allows testing of wafers up to 300mm diameter, including thinned wafers on tape frame with exposed through-silicon vias. After several years of intense collaboration between imec and Cascade Microtech, partly supported by the EU-funded FP7 SEA4KET project, good results were achieved with Cascade Microtech’s Pyramid Probe® prototype RBI probe cards on imec’s 300mm wafers with 40µm-pitch micro-bumped chips.

“Imec provided us with unique early insights into the test requirements for 3D ICs, which drove the development of this system,” said Jörg Kiesewetter, director of engineering at Cascade Microtech Dresden. “Also the availability of imec’s dedicated micro-bump test wafers has helped us to fine-tune both the probe station and the probe cards for this application.”

“At imec, we are using the system now on a routine basis to test our 40µm-pitch micro-bumped wafers,” stated Erik Jan Marinissen, principal scientist at imec. “As everything in the semiconductor realm, also micro-bumps are subject to downscaling. Hence, with Cascade, we have started experiments to also probe our 20µm-pitch micro-bump arrays, and those look promising.”



Mems-basedProbe

  At the heart of the test system is this probe core with MEMS-based probe tips that contact the large arrays of fine-pitch micro-bumps.



About imec

Imec is the world-leading research and innovation hub in nano-electronics and digital technologies. The combination of our widely-acclaimed leadership in microchip technology and profound software and ICT expertise is what makes us unique. By leveraging our world-class infrastructure and local and global ecosystem of partners across a multitude of industries, we create groundbreaking innovation in application domains such as healthcare, smart cities and mobility, logistics and manufacturing, and energy.

As a trusted partner for companies, start-ups and universities we bring together close to 3,500 brilliant minds from over 75 nationalities. Imec is headquartered in Leuven, Belgium and also has distributed R&D groups at a number of Flemish universities, in the Netherlands, Taiwan, USA, China, and offices in India and Japan. In 2016, imec's revenue (P&L) totaled 496 million euro. Further information on imec can be found at www.imec-int.com

Imec is a registered trademark for the activities of IMEC International (a legal entity set up under Belgian law as a "stichting van openbaar nut”), imec Belgium (IMEC vzw supported by the Flemish Government), imec the Netherlands (Stichting IMEC Nederland, part of Holst Centre which is supported by the Dutch Government), imec Taiwan (IMEC Taiwan Co.) and imec China (IMEC Microelectronics (Shanghai) Co. Ltd.) and imec India (Imec India Private Limited), imec Florida (IMEC USA nanoelectronics design center).

About FormFactor

FormFactor, Inc. (NASDAQ:FORM), is a leading provider of essential test and measurement technologies along the full IC life cycle – from characterization, modeling, reliability, and design de-bug, to qualification and production test. Semiconductor companies rely upon FormFactor’s products and services to accelerate profitability by optimizing device performance and advancing yield knowledge. The Company serves customers through its network of facilities in Asia, Europe, and North America. For more information, visit the Company’s website at www.formfactor.com.

Contact

Imec: Hanne Degans, Press communication manager, T: +32 16 28 17 69, Mobile : +32 486 06 51 75, Hanne.Degans@imec.be

FormFactor: Amy Leong, Marketing, T: +1 408 468-8132, aleong@formfactor.com
